M12II-850 EVO

The quiet operation of this newly enhanced unit is clearly one of its advantages. It is equipped with a fluid dynamic bearing fan and a matching high performance fan control that is set to regulate the rotation of the fan to achieve the most desirable balance between silence and the necessity of cooling. The fully modular flat black cables are neat and easily organized, leaving more room for proper cooling inside the computer case. Durable components, clean power and all the essential functions that enthusiastic gamers require will make this choice hard to resist.

SKU: SS-850AM2 Active PFC Categories: Consumer Products, M12II EVO Series

Features
Specifications
Cables
Downloads
Awards
Gallery

Fully Modular Cables

In Sea Sonic’s patented design feature full modularity comes hand-in-hand with the extensive use of SMD technology to increase the overall performance and reliability of this power supply. The simple and inventive layout scheme helps to attain unsurpassed quality and performance, where efficiency is further enhanced by minimized line resistance, reduced voltage drop and lower impedance. Reduced component count and better space utilization facilitate optimal air flow inside the case and promote heat dissipation, proper cooling and ultimately longer product life.

80 PLUS^®Bronze

The 80 PLUS^® Bronze certification indicates that a high percentage of the electricity is converted into useful power, therefore there is less heat lost and more money saved on the electricity bill. The 80 PLUS^® Bronze certification guarantees greater than 82 %, 85 % and 82 % efficiency at 20 %, 50 % and 100 % operating loads, respectively. Sea Sonic’s Bronze Series is an economical choice with great performance and high built-in value.

Fluid Dyanamic Fan Bearing

High performance Fluid Dynamic Bearing (FDB) fans are designed to take advantage of the impact absorbance effects of oil. They are extremely reliable and generate considerably less operating noise and heat than ball bearing fans. The lubrication of the bearing surface reduces friction and vibration and therefore lowers overall power consumption. Due to the effortless, quieter rotations and its robust construction, this reliable fan technology also greatly increases the lifespan of the fan.

How it works

When the fan shaft rotates, high pressure oil drifts along the grooves of the bearing sleeve to generate a thin layer of lubrication between the bearing faces. As the speed increases, so does dynamic oil pressure and the shaft is lifted from the bearing to create smooth, effortless rotations. The herringbone shape of the groves helps to efficiently channel the lubricant and avert leakage.
The following illustration depicts the main characteristics of the FDB fans:

Solid Capacitor

Highly rated capacitors ensure long-term stability and reliability even under extreme conditions.

Universal AC Input

Switch-mode power supplies can tolerate a wide range of power frequencies and voltages. The power supply is designed to automatically adjust to the inpout AC voltage, therefore it can safely be used anywhere in the world.

Specifications are subject to change without prior notice.

M12II-850 EVO
AC Input	Voltage: 100 V - 240 V
	Current: 12 A
	Frequency: 50 Hz - 60 Hz
DC Output	Rail	+3.3 V	+5 V	+12 V	-12 V	+5 V_SB
	Maximum Power	25 A	25 A	70 A	0.5 A	3 A
	Maximum Power	150 W Max.		840 W	6 W	15 W
	Total continuous power	850 W

M12II-850 EVO Technical Specifications
80PLUS^®		Bronze
Form Factor		Intel ATX 12 V
Dimensions		150 mm (W) x 170 mm (L) x 86 mm (H)
Fan Information	Fan Size	120 mm
	Fan Control	Seasonic S²FC
	Fan Bearing	Fluid Dynamic Bearing
	Life Expectancy	50,000 at 40 °C, 15 % - 65 % R.H.
Cable Information	Modularity	Fully Modular
Cable Information	Cable type	Flat black cables
Electrical Features	Operating Temperature	40 °C
	MTBF @ 25 °C, excl. fan	100,000 hours
	AC Input	Full Range
	Protection	OPP, OVP, UVP, SCP
Safety and Environmental	Safety and EMC	cTUVus, TUV, Gost-R, UkrTEST, CB , BSMI, CCC, Semko, CE, FCC, C-tick
Safety and Environmental	Environmental Compliance	Energy Star, RoHS, WEEE, ErP Lot 6, REACH
Warranty		5 Years

Packaging information
Units per carton	4
Individual carton size	330 (L) x 130 (W) x 195 (H) mm
Shipping carton size	545 (L) x 215 (W) x 360 (H) mm

Specifications are subject to change without prior notice.

Connector	Connector Count	Lengths
	1	610 mm - modular
	2	650 mm - 8 pin modular 650 mm - 4+4 pin modular
	6	550 + 100 mm - 6/8 pin modular 550 + 100 mm - 6/8 pin modular 550 + 100 mm - 6/8 pin modular
	10	400 + 120 + 120 + 120 mm - modular 400 + 120 + 120 + 120 mm - modular 300 + 120 mm - modular
	5	400 + 120 + 120 mm - modular 300 + 120 mm - modular
	1	101 mm - modular
