Snow Silent 750

80 PLUS^®Platinum

The higher the level of efficiency of the power supply, the less power gets wasted in the form of excess heat . The 80 PLUS^® Platinum certification guarantees greater than 90 %, 92 % and 89 % efficiency at 20 %, 50 % and 100 % operating loads, respectively. The Seasonic Platinum Series represents the highest level of technology and efficiency achievement of Sea Sonic during its 40 years of commitment to engineering excellence.

7 Years Warranty

Our commitment to superior Seasonic quality.

Fluid Dyanamic Fan Bearing

High performance Fluid Dynamic Bearing (FDB) fans are designed to take advantage of the impact absorbance effects of oil. They are extremely reliable and generate considerably less operating noise and heat than ball bearing fans. The lubrication of the bearing surface reduces friction and vibration and therefore lowers overall power consumption. Due to the effortless, quieter rotations and its robust construction, this reliable fan technology also greatly increases the lifespan of the fan.

How it works

When the fan shaft rotates, high pressure oil drifts along the grooves of the bearing sleeve to generate a thin layer of lubrication between the bearing faces. As the speed increases, so does dynamic oil pressure and the shaft is lifted from the bearing to create smooth, effortless rotations. The herringbone shape of the groves helps to efficiently channel the lubricant and avert leakage.
The following illustration depicts the main characteristics of the FDB fans:

What is S³FC?

The industry’s first, Seasonic patented, advanced three-phased thermal control balances between silence and cooling. This Hybrid Silent Fan Control functions in three operational stages: Fanless Mode, Silent Mode, and Cooling Mode. In addition, there is a switch provided to allow for manual selection between the Seasonic S2FC (fan control without Fanless Mode) and the S3FC (fan control including Fanless Mode).

New! Power saving by hysteresis

Hysteresis is achieved by an additional fan control IC, which optimizes how frequently the fan switches on and off. At 25 °C ambient temperature the fan turns on when the load rises above 50 % (±5 %) and it turns off when the load drops below 40 % (±5 %). Due to this lag in response the fan switches on and off less frequently, which reduces noise and power loss in Fanless Mode and Silent Mode.

Ultra Stable Voltage Regulation

Intel guidelines specify that the DC output voltages have to remain within the regulation range of +/- 5 %. However, power supply testers and reviewers prefer to have this allowance down to +/- 3 %. Seasonic has implemented and even stricter voltage regulation which entirely eliminates negative deviations and keeps voltage 80% tighter than Intel specifications and 66 % tighter than top reviewers recommend. The result of clean output power is quicker CPU response and a better overclocking performance.

Dual Copper Bars

Due to their increased diameter, pure copper bars carry high current much more effectively than the traditional copper strips. If the goal is to achieve high quality power conversion with stable power output and minimized loss, it is very important that power conduction in the high wattage area remains extremely efficient, because it also reduces impedance and minimizes voltage drop as the load increases.

Hispazone | Editor’s Choice

November 03, 2015

“Tiene la ventaja adicional de que es más corta y por tanto más compatible con sistemas más compactos, que están cada día más de moda.”

(Read More)

Nexthardware | 5 Stars

September 17, 2015

“La livrea bianca e i pregevoli dettagli colgono ancora nel segno, ammaliando tutti i potenziali acquirenti, amanti del modding in primis, che cercano un prodotto che si distingua dalla massa e riesca a far sfoggio di sé nelle proprie postazioni. ”

(Read More)

Conseil Config | 4.5/5

August 13, 2015

“Une stabilité à toute épreuve, des composants internes haut de gamme, un rendement de haut vol, un silence de cathédrale et une finition exceptionnelle grâce à une peinture blanche haut de gamme qui ravira les amateurs de produits sortant de l’ordinaire, voici ce qui ressort de la Seasonic Snow Silent 750.”

(Read More)

tom’s HARDWARE | Editor Recommended

July 18, 2015

“The Snow Silent-750 is a top-notch Seasonic unit offering a unique look, high performance and silent operation, thanks to the quality FDB fan, the relaxed fan profile and the semi-passive mode.”

(Read More)

hardwareLUXX | Excellent Hardware

July 10, 2015

“Das Snow Silent 750W bietet eine gute Effizienz, niedrige Ripple-Noise-Spannungen und vor allem eine exzellente Spannungsregulierung.”

(Read More)

HardOCP | Gold Award

July 09, 2015

“Buy it. Sorry, that sort of slipped out so let’s try that again. The Seasonic Snow Silent 750W did well in almost all of our performance metrics today and in the one metric that it did not do well in it sort of made up a new superlative for how it did in that one.”

(Read More)

TECHPOWEUP | 9.5/10

June 17, 2015

“…this unit screams of quality and offers top-notch performance in all areas (load regulation, efficiency, and ripple suppression). Even its noise output, where Seasonic’s high-end units usually struggle, is excellent as it easily outperforms its big brother with a faster fan.”

(Read More)

Cowcotland | Gold Award

June 17, 2015

“Seasonic nous livre une alimentation de 750 watts qui frôle la perfection”

(Read More)

KitGURU | Must Have

May 21, 2015

“…an eye catching design…stable leveles of power…ripple suppression is escellent, load regualtion is stellar, and overall efficiency is extrelmelyhigh.”

(Read More)
