TFX-350

The TFX-350 is the highest wattage TFX power supply on the retail market today with more than enough power to support a dedicated high performance PCIe connection. Due to its small size and remarkable fan control system, it is a compact, cool and quiet source of power, making it ideal for low profile home entertainment systems or other setups using mini-ITX motherboards. It is the first fully modular TFX unit boasting with Sea Sonic’s popular ATX features, such as tight voltage regulation, highly reliable 105°C aluminum electrolytic capacitors and customizable flat black cables – all in all; a true marvel of Sea Sonic engineering.

SKU: SS-350TGM Active PFC Categories: ,
80plus-gold

80 PLUS®Gold

Seasonic was the forerunner of creating the very first 80 PLUS® Gold certified power supply on the market and since that time it has built a very popular Gold series lineup that covers a full power range of power supplies with impeccable performance and efficiency. The highly efficient 80 PLUS® Gold certification guarantees greater than 87 %, 90 % and 87 % efficiency at 20 %, 50 % and 100 % operating loads, respectively. The clear advantage of buying a power supply with 80 PLUS® Gold rating is the fact that the less energy gets wasted during power conversion, the lower the operating costs will be for the user.

Fan Control S3FC-01

Hybrid Silent fan Control

The industry’s first, Seasonic patented, advanced three-phased thermal control achieves optimal between silence and cooling. This Hybrid Silent Fan Control functions in three operational stages: Fanless Mode, Silent Mode, and Cooling Mode.

S3FC

Benefits of this design

  • Reduced noise without increase in temperature;
  • Extended fan life due to the reduced number of fan rotations;
  • Optimized heat dissipation at all times;
  • Unsurpassed silent performance in Fanless Mode.

Additionally, there is a switch at the back of the power supply which allows users to customize their cooling needs by selecting between the Seasonic S2FC (fan control without Fanless Mode) and the S3FC (fan control including Fanless Mode).

Modular Cables-01

Fully Modular Cables

In Sea Sonic’s patented design feature full modularity comes hand-in-hand with the extensive use of SMD technology to increase the overall performance and reliability of this power supply. The simple and inventive layout scheme helps to attain unsurpassed quality and performance, where efficiency is further enhanced by minimized line resistance, reduced voltage drop and lower impedance. Reduced component count and better space utilization facilitate optimal air flow inside the case and promote heat dissipation, proper cooling and ultimately longer product life.

Gold Plated Connectors-01

Gold Plated Connectors

Gold plating critical connector pins (motherboard, CPU and PCIe cables) extends the lifetime of the connectors and greatly increases the efficiency of current transmission.

Solid Capacitor-01

Solid Capacitor

Highly rated capacitors ensure long-term stability and reliability even under extreme conditions.

Tight Voltage Regulation-01

Tight Voltage Regulation (3 %)

Seasonic’s advanced design is to improve load regulation which reduces voltage variations to provide smooth and stable operations.

Universal AC Input-01

Universal AC Input

Switch-mode power supplies can tolerate a wide range of power frequencies and voltages. The power supply is designed to automatically adjust to the inpout AC voltage, therefore it can safely be used anywhere in the world.

5 Years Warranty-01

5 Years Warranty

Our commitment to superior Seasonic quality.

Specifications are subject to change without prior notice.

TFX-350
AC Input Voltage: 100 V - 240 V
Current: 7 A
Frequency: 50 Hz - 60 Hz
DC Output Rail +3.3 V +5 V +12 V1 +12 V2 -12 V +5 VSB
Maximum Power 12 A 16 A 18 A 18 A 0.3 A 2 A
80 W 348 W 3.6 W 10 W
Total continuous power 350 W
TFX-350 Technical Specifications
80PLUS® Gold
Form Factor Intel TFX 12 V
Dimensions 175 mm (W) x 85 mm (L) x 65 mm (H)
Fan Information Fan Size 80 mm
Fan Control Seasonic S3FC
Fan Bearing Double Ball Bearing
Life Expectancy 70,000 at 40 °C, 15 % - 65 % R.H.
Cable Information Modularity Fully Modular
Cable type Flat black cables
Electrical Features Operating Temperature 40 °C
MTBF @ 25 °C, excl. fan 100,000 hours
AC Input Full Range
Protection OPP, OVP, UVP, SCP
Safety and Environmental Safety and EMC cULus, TUV, CB, CE, C-tick, FCC
Environmental Compliance Energy Star, RoHS, WEEE, ErP Lot 6, REACH
Warranty 5 Years
Packaging information
Units per carton 10
Individual carton size 250 (L) x 173 (W) x 105 (H) mm
Shipping carton size 550 (L) x 275 (W) x 366 (H) mm
Specifications are subject to change without prior notice.

Connector Connector Count Lengths
MAIN-POWER-24-20-PIN-A 1 350 mm - modular
PCIE-8-PIN-A 1 350 mm - modular
PCIE-6-8-PIN-1-A 1 350 + 100 mm - modular
SATA-5-PIN-A 4 350 + 150 mm
350 + 150 mm
PERIPHERAL-4-PIN-A 2 350 + 100 mm - modular
FDD-4-PIN-1-A 1 150 mm - FDD is the end connector of the Peripheral cable
Specifications are subject to change without prior notice.

User-Manual-01

User-Manual-02

User-Manual-03
User-Manual-04

HISPAZONE | Recommended

September 16, 2015

“Los 350w de la Seasonic TFX-350 pueden parecer poco pero una grafica decente, incluso una potente como la Radeon R9 Nano de AMD, consumen menos de 200w, un procesador modelo unos 75w y un SSD de calidad unos 5w en carga. Creo que la suma sale y por tanto estos 350w pueden suponer el tener un PC de muy altas prestaciones en un formato realmente compacto.”

(Read More)

Hardward LUXX | Excellent Hardward

August 14, 2015

“Die Schwierigkeiten aufgrund des beengten Gehäuses meistert Seasonic sehr gut und so kann das TFX 350W auch dank seiner ausgereiften semi-passiven Lüftersteuerung sich auch für Anwendungen in “Wohnzimmersystemen” empfehlen.”

(Read More)
