Platinum 860

The highest grade components make this Seasonic platform an unbelievable performer. It features a high-tech LLC/full-bridge circuit topology with a unique DC Connector Panel with an embedded Voltage Regulator Module. Gold-plated high current terminals ensure optimal signal transfer to the connected peripherals. Due to its multi-GPU processing capability and SLI or Crossfire support, the Platinum 860 can handle really heavy workloads. It is Intel Fourth Generation Haswell CPU-ready, quiet, and it boasts enhanced voltage regulation that suppresses ripple noise to deliver stability. This a robust but elegant‑looking power supply, which is further enhanced by fully modular flat black cables that will make system building a joy.

SKU: SS-860XP2 Active PFC Categories: ,
7 Years Warranty-01

7 Years Warranty

Our commitment to superior Seasonic quality.

80plus-platinum

80 PLUS®Platinum

The higher the level of efficiency of the power supply, the less power gets wasted in the form of excess heat . The 80 PLUS® Platinum certification guarantees greater than 90 %, 92 % and 89 % efficiency at 20 %, 50 % and 100 % operating loads, respectively. The Seasonic Platinum Series represents the highest level of technology and efficiency achievement of Sea Sonic during its 40 years of commitment to engineering excellence.

DC to DC Converter Design-01

DC to DC Converter Design

The step down DC to DC converter design allows the power supply to be able to serve system components with various voltage needs. Not only is it a flexible, clean voltage conversion solution but it also maximizes the 12 V DC rail output, delivers superior dynamic response and , ultimately, provides for greater system stability.

Japanese Capacitor-01

105 °C Japanese Capacitor

Premium quality Japanese capacitors with 105 °C rating increase overall reliability and extend product life.

Fan Type Sanyo Denki-01

Sanyo Denki Fan

The world-renowned Sanyo Denki ball bearing fans are made of the highest quality components to ensure ultra-low noise performance. The fan’s perfect balance and even rotations are achieved via the use of spoon-shaped, high-density plastic fan blades that are finished off with smoothed leading edges. Sanyo Denki fans are known for their strict tolerance ball bearings and precision copper axels. Instead of the industry standard of two balancing points they use three points to strengthen the mount and further stabilize the blade.

Fan Control S3FC-01

Hybrid Silent fan Control

The industry’s first, Seasonic patented, advanced three-phased thermal control achieves optimal between silence and cooling. This Hybrid Silent Fan Control functions in three operational stages: Fanless Mode, Silent Mode, and Cooling Mode.

S3FC

Benefits of this design

  • Reduced noise without increase in temperature;
  • Extended fan life due to the reduced number of fan rotations;
  • Optimized heat dissipation at all times;
  • Unsurpassed silent performance in Fanless Mode.

Additionally, there is a switch at the back of the power supply which allows users to customize their cooling needs by selecting between the Seasonic S2FC (fan control without Fanless Mode) and the S3FC (fan control including Fanless Mode).

Specifications are subject to change without prior notice.
Note: Since the beginning of 2015, Seasonic has implemented changes in its retail box design and modular cables are now packed in a black cardboard box.

Platinum 860
AC Input Voltage: 100 V - 240 V
Current: 11 - 5.5 A
Frequency: 50 Hz - 60 Hz
DC Output Rail +3.3 V +5 V +12 V -12 V +5 VSB
Maximum Power 25 A 25 A 71 A 0.5 A 3 A
125 W 852 W 6 W 15 W
Total continuous power 860 W
Platinum 860 Technical Specifications
80PLUS® Platinum
Form Factor Intel ATX 12 V
Dimensions 150 mm (W) x 160 mm (L) x 86 mm (H)
Fan Information Fan Size 120 mm
Fan Control Seasonic S3FC
Fan Bearing Double Ball Bearing
Life Expectancy 70,000 at 40 °C, 15 % - 65 % R.H.
Cable Information Modularity Fully Modular
Cable type Flat black cables
Electrical Features Operating Temperature 40 °C
MTBF @ 25 °C, excl. fan 150,000 hours
AC Input Full Range
Protection OPP, OVP, UVP, OCP, OTP, SCP
Safety and Environmental Safety and EMC cTUVus, TUV, Gost-R, CB , BSMI, CCC, CE, FCC, C-tick
Environmental Compliance Energy Star, RoHS, WEEE, ErP Lot 6, REACH
Warranty 7 Years
Packaging information
Units per carton 4
Individual carton size 330 (L) x 130 (W) x 195 (H) mm
Shipping carton size 545 (L) x 215 (W) x 360 (H) mm
Specifications are subject to change without prior notice.

Connector Connector Count Lengths
MAIN-POWER-24-20-PIN-A 1 610 mm - modular
PCIE-8-PIN-A 3 650 mm - 8/4 pins modular
650 mm - 8 pins modular
8 Pin - 650 mm - modular
PCIE-6-8-PIN-1-A 6 600 mm - modular
600 mm - modular
550 + 100 mm - modular
550 + 100 mm - modular
SATA-5-PIN-A 10 400 + 120 + 120 + 120 mm - modular
400 + 120 + 120 + 120 mm - modular
300 + 120 mm - modular
PERIPHERAL-4-PIN-A 5 400 + 120 + 120 mm
300 + 120 mm
FDD-4-PIN-1-A 1 101 mm
Specifications are subject to change without prior notice.
